AC 10V~220V Electronic Motor Speed Controller Regulate 4000W

Product: 4000W AC voltage regulator

SCR Model: BTA41600B

Size: L 65 W 45 H 40mm, Knob Diameter 27mm, height 15mm

Maximum power: 4000W (resistive load)

Efficiency: 95%

Operating voltage: 220V AC (180-280V)

Regulate voltage: AC 0-220V

SCR Current: 41 A

SCR voltage: 800V

Radiator: 10 thick corrugated surface aluminum radiator

Thermal Grease: High thermal conductivity thermal grease containing silver

Resistance: Full metal film, precision power resistors

Capacitors: CBB high voltage 630V, and safety certification of MKP capacitors

Potentiometer: 2w power adjustable potentiometer, stable and durable voltage smoothing

How to use:

To put this product series with the lamp or in electrical circuits, (for example, the lamp can connect two wires) rotary potentiometer rotating rod, you can adjust the play of light and shade, speed, pressure, temperature control effect ; easy to use.

This product is suitable for: using the new two-way high-power thyristor, because current up to 40 A, a good solution to the problem of over-current electric wire in the case of cooling the resistance is too small to cause; and can easily adjust the mains the output voltage between 0 and 220 volts ---- any adjustment for the use of electrical appliances. Such as: furnace, hot water heater tune, dimming lamps, small motor speed, electric iron thermostat and so on. So as to achieve dimming, thermostats, pressure effect. Less than 4000 watts of electrical power for large appliances use because the power has been great, so the general home appliances or small factories enough to use. (Inductive or capacitive load power should be reduced, this regulator is equipped with two-way high-power thyristor, potentiometers are with nuts, do not add any components to use, very convenient and practical).
